ELECTRIC MOTOR OPERATED

'VIP' Hydraulic tested pumps are simple design and robust construction. Meeting the demands of any industry needed to do the job, exacting quality long. Lasting satisfactory service, under severe field condition.

CRANK CASE :
The crank case is of sturdy design, completely sealed and made out of special cast iron.
CROSS HEAD :
Larger bearing area full piston type, ensure accurate plunger alignment and also minimized side thrust and wear.
CONNECTING ROD'S :
Accrately machined crank shaft made of alloy steel.
CRANK SHAFT :
Heavy duty accurately machined crank shaft made of alloy steel.
LUBRICATION :
Lubrication of power end parts, bearings are done by splash lubrication system from reservior oil in the crank case.
BEARING :
High quality taper Bearings are used providing support to the crank shaft at both ends.
GLAND PACKING :
PTFE or Nitrile rubber.
PLUNGERS :
Hard Crome plated made of stainless steel materials.


HYDRAULIC PRESSURE RANGE: Up to 705 kg/cm2 (10,000 PSI)
Application: Hydraulic tested of pressure vessels, Gas Cylinders, Boilers, Valves, Pipes & Tubes, Casting,                   rubber hoses or any parts subjected to Hydraulic Pressure.
Standard : Pressure guage, Pressure Hoses 1.5 mtrs. long, pressure release cock, Relief
Accessories valve, Pulley.

---



MANUFACTURING RANGE :
1. VIPH-100 for 35 kg/cm2 (500 PSI) Testing: Having M.S Body,Heavy duty M.S Handle and Fulcrum with
standard fitting,Pail size 15 litres.

2. VIPH-200 for 70 kg/cm2 (100 PSI) testing: Having M.S Body,M.S Handle and Fulcrum with standard fitting, Fabricated M.S Pail size 25 litres.

3. VIPH-300 for 105 kg/cm2 (1500 PSI) Testing: Having M.S Body, Stainless steel piston, Heavy duty M.S Handle and Fulcrum with standard filtings, Mounted on M.S Fabricated Pail size 25 litres.

4. VIPH-400 for 140 kg/cm2 (2000 PSI) Testing: Having M.S Body, Stainless steel piston, Heavy duty M.S Handle and Fulcrum with standard filtings, Mounted on M.S Fabricated Pail size 25 litres.

5. VIPH-500 for 211 kg/cm2 (3000 PSI) Testing: Having S.S 410 Body,Stainless steel piston, Heavy duty M.S Handle and Fulcrum with standard filtings, Mounted on M.S Fabricated Pail size 25 litres.

6. VIPH-600 for 352 kg/cm2 (5000 PSI) Testing: Having S.S 410 Body, Stainless steel piston, Heavy duty M.S Handle and Fulcrum with standard filtings, Mounted on M.S Fabricated Pail size 25 litres.

7. VIPH-700 for 500 kg/cm2 (7100 PSI) Testing: Having S.S 410 Body,Stainless steel piston, Heavy duty M.S Handle and Fulcrum with standard filtings, Mounted on M.S Fabricated Pail size 25 litres with base.

8. VIPH-800 for 705 kg/cm2 (10,000 PSI) Testing: Having S.S 410 Body, Stainless steel piston, Heavy duty M.S Handle and Fulcrum with standard filtings, Mounted on M.S Fabricated Pail size 25  litres with base.


STANDARD ACCESSORIES:
M.S Fabricated pail, Brass foot valve, G.M/S.S check valves, Brass Pressure Release cock, Pressure Hoses with Attachments, Pressure guage.

APPLICATION:
Hydraulic testing of Boilers, Pressure Vessels, C.I Mains, Castings,Gas Cylinders,valves Hydro testing any Parts Subjected to Hydraulic Pressure.
